Specifications#
- Brand
- Leica
- Model
- D-Lux 2
- Camera type
- Compact
- Released
- 2005-01-01
- Sensor size
- 7.8 × 5.9 mm (1/1.7" sensor)
- Crop factor
- 4.45×
Specifications merged from Wikidata, Lensfun and openMVG. Spot an error? Tell us.
Sensor size compared#
Focal length equivalents & field of view#
Multiply any focal length by 4.45 to get the full-frame field of view. For fixed-lens cameras use the real focal length printed on the lens (e.g. “6.1–18.3 mm”), not the 35 mm equivalent.
| Lens on this camera | Full-frame equivalent | Horizontal | Vertical | Diagonal |
|---|---|---|---|---|
| 4 mm | 18 mm | 88.3° | 72.4° | 101.1° |
| 4.5 mm | 20 mm | 81.5° | 66.1° | 94.4° |
| 5 mm | 22 mm | 75.6° | 60.7° | 88.4° |
| 6 mm | 27 mm | 65.8° | 52.1° | 78.0° |
| 8 mm | 36 mm | 51.7° | 40.2° | 62.6° |
| 10 mm | 44 mm | 42.4° | 32.7° | 51.9° |
| 12 mm | 53 mm | 35.8° | 27.4° | 44.1° |
| 15 mm | 67 mm | 29.0° | 22.1° | 35.9° |
| 20 mm | 89 mm | 22.0° | 16.7° | 27.3° |
| 25 mm | 111 mm | 17.6° | 13.4° | 22.0° |
| 30 mm | 133 mm | 14.7° | 11.2° | 18.4° |
| 40 mm | 178 mm | 11.1° | 8.4° | 13.9° |
| 50 mm | 222 mm | 8.9° | 6.7° | 11.1° |
| 70 mm | 311 mm | 6.3° | 4.8° | 7.9° |
| 100 mm | 445 mm | 4.4° | 3.4° | 5.6° |
| 150 mm | 667 mm | 3.0° | 2.2° | 3.7° |
Depth of field table#
Total depth of field at each subject distance, using a circle of confusion of 6.7 µm (the 0.030 mm full-frame standard scaled by the crop factor).
| Focal | Aperture | 50.0 cm | 1.00 m | 2.00 m | 3.00 m | 5.00 m | 10.0 m | Hyperfocal |
|---|---|---|---|---|---|---|---|---|
| 5 mm | f/2 | 28.7 cm | 1.51 m | ∞ | ∞ | ∞ | ∞ | 1.86 m |
| 5 mm | f/2.8 | 43.5 cm | 3.45 m | ∞ | ∞ | ∞ | ∞ | 1.33 m |
| 5 mm | f/4 | 74.7 cm | ∞ | ∞ | ∞ | ∞ | ∞ | 93.2 cm |
| 5 mm | f/8 | ∞ | ∞ | ∞ | ∞ | ∞ | ∞ | 46.8 cm |
| 10 mm | f/2 | 6.6 cm | 27.2 cm | 1.16 m | 2.89 m | 12.3 m | ∞ | 7.43 m |
| 10 mm | f/2.8 | 9.3 cm | 38.7 cm | 1.75 m | 4.97 m | 83.7 m | ∞ | 5.31 m |
| 10 mm | f/4 | 13.5 cm | 57.5 cm | 3.02 m | 13.8 m | ∞ | ∞ | 3.72 m |
| 10 mm | f/8 | 28.4 cm | 1.49 m | ∞ | ∞ | ∞ | ∞ | 1.86 m |
| 17 mm | f/2 | 2.3 cm | 9.2 cm | 37.3 cm | 85.2 cm | 2.46 m | 11.9 m | 21.4 m |
| 17 mm | f/2.8 | 3.2 cm | 12.9 cm | 52.7 cm | 1.22 m | 3.64 m | 22.7 m | 15.3 m |
| 17 mm | f/4 | 4.5 cm | 18.5 cm | 76.6 cm | 1.81 m | 5.93 m | 141 m | 10.7 m |
| 17 mm | f/8 | 9.1 cm | 38.0 cm | 1.72 m | 4.84 m | 68.9 m | ∞ | 5.37 m |
| 28 mm | f/2 | 0.8 cm | 3.3 cm | 13.6 cm | 30.8 cm | 86.1 cm | 3.53 m | 58.2 m |
| 28 mm | f/2.8 | 1.1 cm | 4.7 cm | 19.0 cm | 43.2 cm | 1.21 m | 5.10 m | 41.6 m |
| 28 mm | f/4 | 1.6 cm | 6.7 cm | 27.3 cm | 62.0 cm | 1.76 m | 7.78 m | 29.1 m |
| 28 mm | f/8 | 3.3 cm | 13.4 cm | 55.3 cm | 1.28 m | 3.87 m | 25.9 m | 14.6 m |
Equivalent aperture#
Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.
Night-sky exposure limits#
Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors. (NPF needs a known resolution and is omitted here.)
| Focal length | 500 rule |
|---|---|
| 4 mm (18 mm eq.) | 28.1 s |
| 5 mm (22 mm eq.) | 22.5 s |
| 6 mm (27 mm eq.) | 18.7 s |
| 8 mm (36 mm eq.) | 14.0 s |
| 11 mm (49 mm eq.) | 10.2 s |
Handheld shutter speed guide#
The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.
| Focal length | No stabilisation (1/equiv. focal) | With 3-stop IS | With 5-stop IBIS |
|---|---|---|---|
| 5 mm | 1/20 s | 0.3 s | 1.3 s |
| 11 mm | 1/50 s | 1/6 s | 0.6 s |
| 22 mm | 1/100 s | 1/13 s | 0.3 s |
| 45 mm | 1/200 s | 1/25 s | 1/6 s |
Lens#
The Leica D-Lux 2 has a built-in, non-interchangeable lens. Use the real focal length of that lens with the tables above; its full-frame equivalent is that number × 4.45.
Similar cameras#
Other 1/1.7" cameras from around the same time.
Frequently asked questions#
What is the crop factor of the Leica D-Lux 2?
The Leica D-Lux 2 has a crop factor of 4.45× relative to 35 mm full frame (diagonal 9.7 mm vs 43.3 mm).
What size is the Leica D-Lux 2 sensor?
7.8 × 5.9 mm (1/1.7"), an area of 45 mm² — 5% of full frame.
Is the Leica D-Lux 2 full frame?
No — its sensor is 1/1.7", which is 19.0× smaller in area than full frame.
How long can I expose the night sky with the Leica D-Lux 2?
With a 5 mm lens (22 mm equivalent) the 500 rule gives 22 s.
