Canon EOS RP Specs, Sensor Size & Crop Factor

Q: What is the crop factor of the Canon EOS RP?

The Canon EOS RP has a crop factor of 1.00× relative to 35 mm full frame (diagonal 43.3 mm vs 43.3 mm).

1.00×

Crop factor

36.0×24.0 mm

Sensor size

864 mm²

Area · 100% of full frame

26.2 MP

Resolution

5.77 µm

Pixel pitch

f/8.6

Diffraction-limited aperture

2019

Release year

Specifications#

Brand: Canon
Model: EOS RP
Camera type: Mirrorless
Released: 2019-03-14
Lens mount: Canon RF
Sensor size: 36.0 × 24.0 mm (Full frame (35 mm))
Crop factor: 1.00×
Resolution: 26.2 MP (6,240 × 4,160 px)
ISO range: 100 – 40,000
Fastest shutter: 1/4,000 s
Continuous shooting: 5 fps
Max video resolution: 4K
Weight: 440 g (15.5 oz)
Sensor: dual-pixel CMOS sensor
Viewfinder: 2.360-million dot OLED EVF
Battery: LP-E17
Dimensions: 132.5 x 85.0 x 70.0 mm
Lens: Interchangeable lens
Predecessor: Canon EOS 6D Mark II (DSLR)
Successor: Canon EOS R8
Made in: Japan
Launch price: USD 1,299 - body only; USD 2,399 - body-and-lens kit
Video: 4K resolution (23.98/25 fps)

Specifications merged from Wikipedia, Wikidata and Lensfun. Spot an error? Tell us.

Sensor size compared#

The Canon EOS RP sensor (highlighted) drawn to scale against common formats. Its area is 100% of a full-frame sensor.

Focal length equivalents & field of view#

Multiply any focal length by 1.00 to get the full-frame field of view. Angles are for a rectilinear lens focused at infinity.

Lens on this camera	Full-frame equivalent	Horizontal	Vertical	Diagonal
10 mm	10 mm	121.9°	100.4°	130.4°
12 mm	12 mm	112.6°	90.0°	122.0°
14 mm	14 mm	104.3°	81.2°	114.2°
16 mm	16 mm	96.7°	73.7°	107.0°
18 mm	18 mm	90.0°	67.4°	100.5°
20 mm	20 mm	84.0°	61.9°	94.5°
24 mm	24 mm	73.7°	53.1°	84.1°
28 mm	28 mm	65.5°	46.4°	75.4°
35 mm	35 mm	54.4°	37.8°	63.4°
40 mm	40 mm	48.5°	33.4°	56.8°
50 mm	50 mm	39.6°	27.0°	46.8°
56 mm	56 mm	35.6°	24.2°	42.2°
70 mm	70 mm	28.8°	19.5°	34.3°
85 mm	85 mm	23.9°	16.1°	28.6°
100 mm	100 mm	20.4°	13.7°	24.4°
135 mm	135 mm	15.2°	10.2°	18.2°
200 mm	200 mm	10.3°	6.9°	12.3°
300 mm	300 mm	6.9°	4.6°	8.2°
400 mm	400 mm	5.2°	3.4°	6.2°
600 mm	600 mm	3.4°	2.3°	4.1°
800 mm	800 mm	2.6°	1.7°	3.1°

Depth of field table#

Total depth of field at each subject distance, using a circle of confusion of 30.0 µm (the 0.030 mm full-frame standard scaled by the crop factor). Detailed tables: 24 mm f/1.8, 24 mm f/2.8, 35 mm f/1.8, 35 mm f/2.8, 50 mm f/1.8, 50 mm f/2.8.

Focal	Aperture	50.0 cm	1.00 m	2.00 m	3.00 m	5.00 m	10.0 m	Hyperfocal
22 mm	f/1.8	5.3 cm	22.1 cm	92.8 cm	2.24 m	8.03 m	∞	8.98 m
22 mm	f/2.8	8.4 cm	35.0 cm	1.56 m	4.23 m	34.1 m	∞	5.78 m
22 mm	f/4	12.0 cm	51.5 cm	2.58 m	9.74 m	∞	∞	4.06 m
22 mm	f/8	25.1 cm	1.27 m	103 m	∞	∞	∞	2.04 m
43 mm	f/1.8	1.3 cm	5.6 cm	22.9 cm	52.2 cm	1.48 m	6.35 m	34.3 m
43 mm	f/2.8	2.1 cm	8.7 cm	35.8 cm	82.1 cm	2.37 m	11.4 m	22.1 m
43 mm	f/4	3.0 cm	12.5 cm	51.6 cm	1.20 m	3.59 m	22.2 m	15.5 m
43 mm	f/8	6.0 cm	25.2 cm	1.09 m	2.70 m	11.0 m	∞	7.75 m
73 mm	f/1.8	0.4 cm	1.9 cm	7.8 cm	17.8 cm	50.1 cm	2.03 m	98.8 m
73 mm	f/2.8	0.7 cm	2.9 cm	12.2 cm	27.7 cm	78.1 cm	3.21 m	63.5 m
73 mm	f/4	1.0 cm	4.2 cm	17.4 cm	39.7 cm	1.12 m	4.71 m	44.5 m
73 mm	f/8	1.9 cm	8.4 cm	35.0 cm	80.5 cm	2.33 m	11.2 m	22.3 m
120 mm	f/1.8	0.1 cm	0.7 cm	2.8 cm	6.5 cm	18.3 cm	74.2 cm	267 m
120 mm	f/2.8	0.2 cm	1.0 cm	4.4 cm	10.1 cm	28.5 cm	1.16 m	172 m
120 mm	f/4	0.3 cm	1.5 cm	6.3 cm	14.4 cm	40.7 cm	1.66 m	120 m
120 mm	f/8	0.6 cm	2.9 cm	12.5 cm	28.9 cm	81.9 cm	3.39 m	60.1 m

Equivalent aperture#

Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.

Aperture on this camera	Full-frame equivalent (depth of field)	Hyperfocal at 43 mm
f/1.2	f/1.2	51.4 m
f/1.4	f/1.4	44.1 m
f/1.8	f/1.8	34.3 m
f/2	f/2.0	30.9 m
f/2.8	f/2.8	22.1 m
f/4	f/4.0	15.5 m
f/5.6	f/5.6	11.0 m
f/8	f/8.0	7.75 m

Diffraction & pixel pitch#

With 5.77 µm pixels, diffraction starts to soften pixel-level detail around f/8.6. For maximum sharpness keep landscapes between f/4.7 and f/9; stopping down further trades detail for depth of field.

Aperture	Airy disk diameter	Spread over	At 100% view
f/2.8	3.8 µm	0.7 px	sharp
f/4	5.4 µm	0.9 px	sharp
f/5.6	7.5 µm	1.3 px	sharp
f/8	10.7 µm	1.9 px	sharp
f/11	14.8 µm	2.6 px	slight softening
f/16	21.5 µm	3.7 px	visibly soft
f/22	29.5 µm	5.1 px	visibly soft

Maximum print sizes#

At 26.2 MP the Canon EOS RP produces 6,240 × 4,160 pixel images. See the 26 megapixel guide or the print size calculator.

Resolution	Typical use	Inches	Centimetres
300 DPI	Photo-lab quality	20.8 × 13.9 in	53 × 35 cm
240 DPI	Fine-art inkjet	26.0 × 17.3 in	66 × 44 cm
200 DPI	Wall print	31.2 × 20.8 in	79 × 53 cm
150 DPI	Poster, viewed from 1 m+	41.6 × 27.7 in	106 × 70 cm

Night-sky exposure limits#

Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors.

Focal length	500 rule	NPF f/1.8	NPF f/2.8	NPF f/4
14 mm (14 mm eq.)	35.7 s	16.9 s	19.4 s	22.4 s
20 mm (20 mm eq.)	25.0 s	11.8 s	13.6 s	15.7 s
24 mm (24 mm eq.)	20.8 s	9.8 s	11.3 s	13.0 s
35 mm (35 mm eq.)	14.3 s	6.7 s	7.7 s	8.9 s
50 mm (50 mm eq.)	10.0 s	4.7 s	5.4 s	6.3 s

Open the NPF / 500 rule calculator →

Handheld shutter speed guide#

The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.

Focal length	No stabilisation (1/equiv. focal)	With 3-stop IS	With 5-stop IBIS
24 mm	1/25 s	0.3 s	1.3 s
50 mm	1/50 s	1/6 s	0.6 s
100 mm	1/100 s	1/13 s	0.3 s
200 mm	1/200 s	1/25 s	1/6 s

Lenses for the Canon EOS RP#

Native Canon RF lenses in our database (48 total). Also adaptable: T-mount (T2), Canon EF, M42 screw mount, Deckel (DKL), Canon EF-S, M39 / LTM (Leica thread).

Canon RF-S 18-150mm F3.5-6.3 IS STM 18–150 mm
Canon RF 24mm F1.4 L VCM 24 mm
Canon RF 24mm F1.8 MACRO IS STM 24 mm
Canon RF 28-70mm F2.8 IS STM 28–70 mm
Canon RF 50mm F1.2 L USM 50 mm
Canon RF 50mm F1.4 L VCM 50 mm
Canon RF 135mm F1.8L IS USM 135 mm
Canon RF 10-20mm f/4L IS STM 10–20 mm
Canon RF-S 10-18mm F4.5-6.3 IS STM 10–18 mm
Laowa 10mm f/2.8 Zero-D FF 10 mm
Sigma 10-18mm F2.8 DC DN | Contemporary 023 10–18 mm
Tamron 11-20mm f/2.8 Di III-A RXD (B060) 11–20 mm
Canon RF 14-35mm F4 L IS USM 14–35 mm
Canon RF 15-30mm F4.5-6.3 IS STM 15–30 mm
Canon RF 15-35mm F2.8L IS USM 15–35 mm
Laowa 15mm f/2.0 Zero-D 15 mm
Canon RF 16mm F2.8 STM 16 mm
Sigma 16-300mm F3.5-6.7 DC OS | C 16–300 mm
Sigma 16mm f/1.4 DC DN Contemporary 16 mm
Sigma 17-40mm F1.8 DC | Art 025 17–40 mm
Tamron 17-70mm F/2.8 Di III-A VC RXD 17–70 mm
Canon RF-S 18-45mm F4.5-6.3 IS STM 18–45 mm
Sigma 18-50mm F2.8 DC DN | Contemporary 021 18–50 mm
Tamron 18-300mm F3.5-6.3 B061 RF 18–300 mm
Canon RF 24-105mm F4-7.1 IS STM 24–105 mm
Canon RF 24-105mm F4L IS USM 24–105 mm
Canon RF 24-240mm F4-6.3 IS USM 24–240 mm
Canon RF 24-50mm F4.5-6.3 IS STM 24–50 mm
Canon RF 24-70mm F2.8L IS USM 24–70 mm
Canon RF 28-70mm F2 L USM 28–70 mm
Canon RF 28mm F2.8 STM 28 mm
Sigma 30mm f/1.4 DC DN 30 mm
Canon RF 35mm F1.4 L VCM 35 mm
Canon RF 35mm F1.8 MACRO IS STM 35 mm
Canon RF 45mm F1.2 STM 45 mm
Canon RF 50mm F1.8 STM 50 mm

Similar cameras#

Other Full frame (35 mm) cameras from around the same time.

Frequently asked questions#

What is the crop factor of the Canon EOS RP?

The Canon EOS RP has a crop factor of 1.00× relative to 35 mm full frame (diagonal 43.3 mm vs 43.3 mm).

What size is the Canon EOS RP sensor?

36.0 × 24.0 mm (Full frame (35 mm)), an area of 864 mm² — 100% of full frame.

Is the Canon EOS RP full frame?

Yes — its sensor is the same 36 × 24 mm size as 35 mm film.

How many megapixels does the Canon EOS RP have?

26.2 megapixels (6,240 × 4,160 pixels), enough for a 21 × 14 inch print at 300 DPI.

What lens mount does the Canon EOS RP use?

The Canon EOS RP uses the Canon RF (flange distance 20.00 mm).

How long can I expose the night sky with the Canon EOS RP?

With a 20 mm lens (20 mm equivalent) the 500 rule gives 25 s and the stricter NPF rule at f/2.8 gives 14 s.
