Sony FX30 Specs, Sensor Size & Crop Factor

Q: What is the crop factor of the Sony FX30?

The Sony FX30 has a crop factor of 1.55× relative to 35 mm full frame (diagonal 28.0 mm vs 43.3 mm).

1.55×

Crop factor

23.3×15.5 mm

Image area

361 mm²

Area · 42% of full frame

26 MP

Resolution

3.73 µm

Pixel pitch

f/5.6

Diffraction-limited aperture

2022

Release year

Specifications#

Brand: Sony
Model: FX30
Also known as: ILME-FX30
Camera type: Film camera
Released: 2022-01-01
Lens mount: Sony E-mount
Film format: APS film (H)
Image area: 23.3 × 15.5 mm (APS-C)
Crop factor: 1.55×
Resolution: 26 MP (6,252 × 4,159 px)
ISO range: 100 – 32,000
Fastest shutter: 1/8,000 s
Max video resolution: 4K
Weight: 646 g (22.8 oz)
Sensor: APS-C
Sensor type: Exmor R CMOS Sensor
Storage: Dual Slot SD, SDHC, SDXC, CFexpress A; UHS-II, UHS-I, CFexpress
Shutter: Electronically-controlled, vertical-traverse, focal-plane type
Flash: External flash
Battery: NP-FZ100 Li-ion
Dimensions: 129.7 x
Lens: Interchangeable lens
Launch price: $1800 USD (body only)
Video: XAVC S, XAVC HS; 4K up to 120 fps,; 1080p up to 120 fps, Raw 4.2k 16bit

Specifications merged from Wikipedia, Wikidata and Lensfun. Spot an error? Tell us.

Sensor size compared#

The Sony FX30 frame (highlighted) drawn to scale against common formats. Its area is 42% of a full-frame sensor, which collects about 1.3 stops less total light at the same exposure.

Focal length equivalents & field of view#

Multiply any focal length by 1.55 to get the full-frame field of view. Angles are for a rectilinear lens focused at infinity.

Lens on this camera	Full-frame equivalent	Horizontal	Vertical	Diagonal
8 mm	12 mm	111.0°	88.2°	120.5°
10 mm	15 mm	98.7°	75.6°	108.9°
12 mm	19 mm	88.3°	65.7°	98.8°
14 mm	22 mm	79.5°	57.9°	90.0°
16 mm	25 mm	72.1°	51.7°	82.3°
18 mm	28 mm	65.8°	46.6°	75.7°
20 mm	31 mm	60.4°	42.4°	70.0°
24 mm	37 mm	51.8°	35.8°	60.5°
28 mm	43 mm	45.2°	30.9°	53.1°
35 mm	54 mm	36.8°	25.0°	43.6°
40 mm	62 mm	32.5°	21.9°	38.6°
50 mm	77 mm	26.2°	17.6°	31.3°
56 mm	87 mm	23.5°	15.8°	28.1°
70 mm	108 mm	18.9°	12.6°	22.6°
85 mm	131 mm	15.6°	10.4°	18.7°
100 mm	155 mm	13.3°	8.9°	15.9°
135 mm	209 mm	9.9°	6.6°	11.8°
200 mm	309 mm	6.7°	4.4°	8.0°
300 mm	464 mm	4.4°	3.0°	5.3°
400 mm	618 mm	3.3°	2.2°	4.0°
600 mm	928 mm	2.2°	1.5°	2.7°
800 mm	1237 mm	1.7°	1.1°	2.0°

Depth of field table#

Total depth of field at each subject distance, using a circle of confusion of 19.4 µm (the 0.030 mm full-frame standard scaled by the crop factor). Detailed tables: 24 mm f/1.8, 24 mm f/2.8, 35 mm f/1.8, 35 mm f/2.8, 50 mm f/1.8, 50 mm f/2.8.

Focal	Aperture	50.0 cm	1.00 m	2.00 m	3.00 m	5.00 m	10.0 m	Hyperfocal
14 mm	f/1.8	8.7 cm	36.3 cm	1.62 m	4.45 m	42.2 m	∞	5.63 m
14 mm	f/2.8	13.7 cm	59.1 cm	3.16 m	15.8 m	∞	∞	3.62 m
14 mm	f/4	20.0 cm	92.1 cm	8.25 m	∞	∞	∞	2.54 m
14 mm	f/8	45.2 cm	4.00 m	∞	∞	∞	∞	1.28 m
28 mm	f/1.8	2.1 cm	8.7 cm	35.4 cm	80.9 cm	2.33 m	11.1 m	22.5 m
28 mm	f/2.8	3.3 cm	13.5 cm	55.7 cm	1.29 m	3.91 m	26.5 m	14.5 m
28 mm	f/4	4.7 cm	19.4 cm	81.2 cm	1.93 m	6.50 m	777 m	10.1 m
28 mm	f/8	9.4 cm	40.0 cm	1.84 m	5.40 m	319 m	∞	5.08 m
48 mm	f/1.8	0.7 cm	2.9 cm	11.8 cm	26.9 cm	75.5 cm	3.09 m	66.0 m
48 mm	f/2.8	1.1 cm	4.5 cm	18.5 cm	42.0 cm	1.18 m	4.97 m	42.5 m
48 mm	f/4	1.5 cm	6.4 cm	26.4 cm	60.3 cm	1.72 m	7.55 m	29.7 m
48 mm	f/8	3.0 cm	12.9 cm	53.5 cm	1.24 m	3.75 m	24.4 m	14.9 m
78 mm	f/1.8	0.2 cm	1.1 cm	4.4 cm	10.1 cm	28.3 cm	1.14 m	174 m
78 mm	f/2.8	0.4 cm	1.6 cm	6.9 cm	15.7 cm	44.0 cm	1.79 m	112 m
78 mm	f/4	0.5 cm	2.4 cm	9.8 cm	22.4 cm	63.0 cm	2.57 m	78.5 m
78 mm	f/8	1.1 cm	4.7 cm	19.7 cm	45.0 cm	1.28 m	5.41 m	39.3 m

Equivalent aperture#

Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.

Aperture on this camera	Full-frame equivalent (depth of field)	Hyperfocal at 28 mm
f/1.2	f/1.9	33.7 m
f/1.4	f/2.2	28.9 m
f/1.8	f/2.8	22.5 m
f/2	f/3.1	20.2 m
f/2.8	f/4.3	14.5 m
f/4	f/6.2	10.1 m
f/5.6	f/8.7	7.24 m
f/8	f/12.4	5.08 m

Diffraction & pixel pitch#

With 3.73 µm pixels, diffraction starts to soften pixel-level detail around f/5.6. For maximum sharpness keep landscapes between f/3.1 and f/6; stopping down further trades detail for depth of field.

Aperture	Airy disk diameter	Spread over	At 100% view
f/2.8	3.8 µm	1.0 px	sharp
f/4	5.4 µm	1.4 px	sharp
f/5.6	7.5 µm	2.0 px	slight softening
f/8	10.7 µm	2.9 px	slight softening
f/11	14.8 µm	4.0 px	visibly soft
f/16	21.5 µm	5.8 px	visibly soft
f/22	29.5 µm	7.9 px	visibly soft

Maximum print sizes#

At 26 MP the Sony FX30 produces 6,252 × 4,159 pixel images. See the 26 megapixel guide or the print size calculator.

Resolution	Typical use	Inches	Centimetres
300 DPI	Photo-lab quality	20.8 × 13.9 in	53 × 35 cm
240 DPI	Fine-art inkjet	26.1 × 17.3 in	66 × 44 cm
200 DPI	Wall print	31.3 × 20.8 in	79 × 53 cm
150 DPI	Poster, viewed from 1 m+	41.7 × 27.7 in	106 × 70 cm

Night-sky exposure limits#

Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors.

Focal length	500 rule	NPF f/1.8	NPF f/2.8	NPF f/4
9 mm (14 mm eq.)	35.9 s	19.4 s	23.3 s	28.0 s
13 mm (20 mm eq.)	24.9 s	13.4 s	16.1 s	19.4 s
16 mm (25 mm eq.)	20.2 s	10.9 s	13.1 s	15.7 s
23 mm (36 mm eq.)	14.1 s	7.6 s	9.1 s	10.9 s
32 mm (49 mm eq.)	10.1 s	5.5 s	6.6 s	7.9 s

Open the NPF / 500 rule calculator →

Handheld shutter speed guide#

The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.

Focal length	No stabilisation (1/equiv. focal)	With 3-stop IS	With 5-stop IBIS
16 mm	1/25 s	0.3 s	1.3 s
32 mm	1/50 s	1/6 s	0.6 s
65 mm	1/100 s	1/13 s	0.3 s
129 mm	1/200 s	1/25 s	1/6 s

Lenses for the Sony FX30#

Native Sony E-mount lenses in our database (174 total). Also adaptable: T-mount (T2), M39 / LTM (Leica thread), M42 screw mount, Deckel (DKL).

Sony FE 12-24mm f/4 G 12–24 mm
Sony FE 20-70mm f/4 G 20–70 mm
Sony FE 20mm f/1.8 G 20 mm
Sony FE 24-105mm f/4 G OSS 24–105 mm
Sony FE 28-60mm f/4-5.6 28–60 mm
Sony FE 28-70mm f/3.5-5.6 OSS 28–70 mm
Sony FE 50mm f/1.2 GM 50 mm
Sony FE 70-200mm f/2.8 GM OSS 70–200 mm
Sony FE 70-200mm f/4 G OSS 70–200 mm
Sony FE 70-300mm f/4.5-5.6 G OSS 70–300 mm
Sony FE 85mm f/1.4 GM 85 mm
Sony FE 85mm f/1.8 85 mm
Sony FE 90mm f/2.8 Macro G OSS 90 mm
Sony FE 200-600mm f/5.6-6.3 G OSS 200–600 mm
Samyang 8mm f/2.8 UMC Fish-eye 8 mm
Samyang 8mm f/3.5 Fish-Eye CS 8 mm
Laowa 9mm f/2.8 Zero-D 9 mm
Laowa 9mm f/5.6 FF RL 9 mm
Viltrox AF 9mm f/2.8 Z/E/XF 9 mm
Laowa 10mm f/2.8 Zero-D FF 10 mm
Samyang 10mm f/2.8 ED AS NCS CS 10 mm
Sigma 10-18mm F2.8 DC DN | Contemporary 023 10–18 mm
Sony E 10-18mm f/4 OSS 10–18 mm
Voigtländer Heliar-Hyper Wide 10mm F5.6 10 mm
Sony E 11mm f/1.8 11 mm
Tamron 11-20mm f/2.8 Di III-A RXD (B060) 11–20 mm
Laowa 12mm f/2.8 Zero-D 12 mm
Samyang 12mm f/2.0 NCS CS 12 mm
Samyang 12mm f/2.8 Fish-Eye ED AS NCS 12 mm
Samyang AF 12mm f/2.0 12 mm
Zeiss Touit 2.8/12 12 mm
Viltrox AF 13mm F1.4 13 mm
Samyang 14mm f/2.8 AE ED AS IF UMC 14 mm
Samyang AF 14mm f/2.8 14 mm
Sigma 14-24mm F2.8 DG DN | Art 019 14–24 mm
Sigma 14mm f/1.8 DG HSM | A 14 mm

Film stocks for the Sony FX30#

Films currently made in 135 format.

Similar cameras#

Other APS-C film cameras from around the same time.

Frequently asked questions#

What is the crop factor of the Sony FX30?

The Sony FX30 has a crop factor of 1.55× relative to 35 mm full frame (diagonal 28.0 mm vs 43.3 mm).

What size is the Sony FX30 frame?

23.3 × 15.5 mm (APS-C), an area of 361 mm² — 42% of full frame.

How many megapixels does the Sony FX30 have?

26 megapixels (6,252 × 4,159 pixels), enough for a 21 × 14 inch print at 300 DPI.

What lens mount does the Sony FX30 use?

The Sony FX30 uses the Sony E-mount (flange distance 18.00 mm).

How long can I expose the night sky with the Sony FX30?

With a 13 mm lens (20 mm equivalent) the 500 rule gives 25 s and the stricter NPF rule at f/2.8 gives 16 s.
