Sony α6300 Specs, Sensor Size & Crop Factor

Q: What is the crop factor of the Sony α6300?

The Sony α6300 has a crop factor of 1.53× relative to 35 mm full frame (diagonal 28.2 mm vs 43.3 mm).

1.53×

Crop factor

23.5×15.6 mm

Sensor size

367 mm²

Area · 42% of full frame

24.3 MP

Resolution

3.92 µm

Pixel pitch

f/5.8

Diffraction-limited aperture

2016

Release year

Specifications#

Brand: Sony
Model: α6300
Also known as: ILCE-6300, Sony ILCE-6300
Camera type: Mirrorless
Released: 2016-01-01
Lens mount: Sony E-mount
Sensor size: 23.5 × 15.6 mm (APS-C)
Crop factor: 1.53×
Resolution: 24.3 MP (6,000 × 4,000 px)
Fastest shutter: 1/4,000 s
Continuous shooting: 8 fps
Weight: 404 g (14.3 oz)
Sensor type: Exmor HD CMOS
Viewfinder: Built-in 2.36 million dots OLED electronic viewfinder
AF points / area: 425 focus points
Flash: hotshoe
Drive: 8 frame/s, 11 frame/s in speed priority mode

Specifications merged from Wikipedia, Wikidata, Lensfun and openMVG. Spot an error? Tell us.

Sensor size compared#

The Sony α6300 sensor (highlighted) drawn to scale against common formats. Its area is 42% of a full-frame sensor, which collects about 1.2 stops less total light at the same exposure.

Focal length equivalents & field of view#

Multiply any focal length by 1.53 to get the full-frame field of view. Angles are for a rectilinear lens focused at infinity.

Lens on this camera	Full-frame equivalent	Horizontal	Vertical	Diagonal
8 mm	12 mm	111.5°	88.5°	120.9°
10 mm	15 mm	99.2°	75.9°	109.3°
12 mm	18 mm	88.8°	66.0°	99.2°
14 mm	21 mm	80.0°	58.2°	90.4°
16 mm	25 mm	72.6°	52.0°	82.8°
18 mm	28 mm	66.3°	46.9°	76.2°
20 mm	31 mm	60.9°	42.6°	70.4°
24 mm	37 mm	52.2°	36.0°	60.9°
28 mm	43 mm	45.5°	31.1°	53.5°
35 mm	54 mm	37.1°	25.1°	43.9°
40 mm	61 mm	32.7°	22.1°	38.8°
50 mm	77 mm	26.4°	17.7°	31.5°
56 mm	86 mm	23.7°	15.9°	28.3°
70 mm	107 mm	19.1°	12.7°	22.8°
85 mm	130 mm	15.7°	10.5°	18.8°
100 mm	153 mm	13.4°	8.9°	16.1°
135 mm	207 mm	9.9°	6.6°	11.9°
200 mm	307 mm	6.7°	4.5°	8.1°
300 mm	460 mm	4.5°	3.0°	5.4°
400 mm	614 mm	3.4°	2.2°	4.0°
600 mm	920 mm	2.2°	1.5°	2.7°
800 mm	1227 mm	1.7°	1.1°	2.0°

Depth of field table#

Total depth of field at each subject distance, using a circle of confusion of 19.6 µm (the 0.030 mm full-frame standard scaled by the crop factor). Detailed tables: 24 mm f/1.8, 24 mm f/2.8, 35 mm f/1.8, 35 mm f/2.8, 50 mm f/1.8, 50 mm f/2.8.

Focal	Aperture	50.0 cm	1.00 m	2.00 m	3.00 m	5.00 m	10.0 m	Hyperfocal
14 mm	f/1.8	8.8 cm	36.6 cm	1.63 m	4.52 m	45.2 m	∞	5.58 m
14 mm	f/2.8	13.8 cm	59.6 cm	3.21 m	16.5 m	∞	∞	3.59 m
14 mm	f/4	20.2 cm	93.1 cm	8.53 m	∞	∞	∞	2.52 m
14 mm	f/8	45.7 cm	4.14 m	∞	∞	∞	∞	1.27 m
28 mm	f/1.8	2.1 cm	8.7 cm	35.7 cm	81.5 cm	2.35 m	11.2 m	22.3 m
28 mm	f/2.8	3.3 cm	13.6 cm	56.2 cm	1.30 m	3.95 m	27.1 m	14.3 m
28 mm	f/4	4.7 cm	19.6 cm	81.9 cm	1.95 m	6.58 m	2.0 km	10.0 m
28 mm	f/8	9.5 cm	40.3 cm	1.86 m	5.49 m	643 m	∞	5.04 m
48 mm	f/1.8	0.7 cm	2.9 cm	11.9 cm	27.1 cm	76.1 cm	3.11 m	65.5 m
48 mm	f/2.8	1.1 cm	4.5 cm	18.6 cm	42.3 cm	1.19 m	5.01 m	42.1 m
48 mm	f/4	1.5 cm	6.5 cm	26.6 cm	60.8 cm	1.73 m	7.63 m	29.5 m
48 mm	f/8	3.1 cm	13.0 cm	54.0 cm	1.25 m	3.79 m	24.9 m	14.8 m
78 mm	f/1.8	0.2 cm	1.1 cm	4.4 cm	10.1 cm	28.5 cm	1.15 m	173 m
78 mm	f/2.8	0.4 cm	1.7 cm	6.9 cm	15.8 cm	44.4 cm	1.80 m	111 m
78 mm	f/4	0.5 cm	2.4 cm	9.9 cm	22.6 cm	63.5 cm	2.59 m	77.8 m
78 mm	f/8	1.1 cm	4.7 cm	19.8 cm	45.3 cm	1.29 m	5.46 m	39.0 m

Equivalent aperture#

Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.

Aperture on this camera	Full-frame equivalent (depth of field)	Hyperfocal at 28 mm
f/1.2	f/1.8	33.4 m
f/1.4	f/2.1	28.7 m
f/1.8	f/2.8	22.3 m
f/2	f/3.1	20.1 m
f/2.8	f/4.3	14.3 m
f/4	f/6.1	10.0 m
f/5.6	f/8.6	7.19 m
f/8	f/12.3	5.04 m

Diffraction & pixel pitch#

With 3.92 µm pixels, diffraction starts to soften pixel-level detail around f/5.8. For maximum sharpness keep landscapes between f/3.2 and f/6; stopping down further trades detail for depth of field.

Aperture	Airy disk diameter	Spread over	At 100% view
f/2.8	3.8 µm	1.0 px	sharp
f/4	5.4 µm	1.4 px	sharp
f/5.6	7.5 µm	1.9 px	sharp
f/8	10.7 µm	2.7 px	slight softening
f/11	14.8 µm	3.8 px	visibly soft
f/16	21.5 µm	5.5 px	visibly soft
f/22	29.5 µm	7.5 px	visibly soft

Maximum print sizes#

At 24.3 MP the Sony α6300 produces 6,000 × 4,000 pixel images. See the 24 megapixel guide or the print size calculator.

Resolution	Typical use	Inches	Centimetres
300 DPI	Photo-lab quality	20.0 × 13.3 in	51 × 34 cm
240 DPI	Fine-art inkjet	25.0 × 16.7 in	64 × 42 cm
200 DPI	Wall print	30.0 × 20.0 in	76 × 51 cm
150 DPI	Poster, viewed from 1 m+	40.0 × 26.7 in	102 × 68 cm

Night-sky exposure limits#

Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors.

Focal length	500 rule	NPF f/1.8	NPF f/2.8	NPF f/4
9 mm (14 mm eq.)	36.2 s	20.1 s	23.9 s	28.6 s
13 mm (20 mm eq.)	25.1 s	13.9 s	16.6 s	19.8 s
16 mm (25 mm eq.)	20.4 s	11.3 s	13.5 s	16.1 s
23 mm (35 mm eq.)	14.2 s	7.8 s	9.4 s	11.2 s
33 mm (51 mm eq.)	9.9 s	5.5 s	6.5 s	7.8 s

Open the NPF / 500 rule calculator →

Handheld shutter speed guide#

The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.

Focal length	No stabilisation (1/equiv. focal)	With 3-stop IS	With 5-stop IBIS
16 mm	1/25 s	0.3 s	1.3 s
33 mm	1/50 s	1/6 s	0.6 s
65 mm	1/100 s	1/13 s	0.3 s
130 mm	1/200 s	1/25 s	1/6 s

Lenses for the Sony α6300#

Native Sony E-mount lenses in our database (174 total). Also adaptable: T-mount (T2), M39 / LTM (Leica thread), M42 screw mount, Deckel (DKL).

Sony FE 12-24mm f/4 G 12–24 mm
Sony FE 20-70mm f/4 G 20–70 mm
Sony FE 20mm f/1.8 G 20 mm
Sony FE 24-105mm f/4 G OSS 24–105 mm
Sony FE 28-60mm f/4-5.6 28–60 mm
Sony FE 28-70mm f/3.5-5.6 OSS 28–70 mm
Sony FE 50mm f/1.2 GM 50 mm
Sony FE 70-200mm f/2.8 GM OSS 70–200 mm
Sony FE 70-200mm f/4 G OSS 70–200 mm
Sony FE 70-300mm f/4.5-5.6 G OSS 70–300 mm
Sony FE 85mm f/1.4 GM 85 mm
Sony FE 85mm f/1.8 85 mm
Sony FE 90mm f/2.8 Macro G OSS 90 mm
Sony FE 200-600mm f/5.6-6.3 G OSS 200–600 mm
Samyang 8mm f/2.8 UMC Fish-eye 8 mm
Samyang 8mm f/3.5 Fish-Eye CS 8 mm
Laowa 9mm f/2.8 Zero-D 9 mm
Laowa 9mm f/5.6 FF RL 9 mm
Viltrox AF 9mm f/2.8 Z/E/XF 9 mm
Laowa 10mm f/2.8 Zero-D FF 10 mm
Samyang 10mm f/2.8 ED AS NCS CS 10 mm
Sigma 10-18mm F2.8 DC DN | Contemporary 023 10–18 mm
Sony E 10-18mm f/4 OSS 10–18 mm
Voigtländer Heliar-Hyper Wide 10mm F5.6 10 mm
Sony E 11mm f/1.8 11 mm
Tamron 11-20mm f/2.8 Di III-A RXD (B060) 11–20 mm
Laowa 12mm f/2.8 Zero-D 12 mm
Samyang 12mm f/2.0 NCS CS 12 mm
Samyang 12mm f/2.8 Fish-Eye ED AS NCS 12 mm
Samyang AF 12mm f/2.0 12 mm
Zeiss Touit 2.8/12 12 mm
Viltrox AF 13mm F1.4 13 mm
Samyang 14mm f/2.8 AE ED AS IF UMC 14 mm
Samyang AF 14mm f/2.8 14 mm
Sigma 14-24mm F2.8 DG DN | Art 019 14–24 mm
Sigma 14mm f/1.8 DG HSM | A 14 mm

Similar cameras#

Other APS-C cameras from around the same time.

Frequently asked questions#

What is the crop factor of the Sony α6300?

The Sony α6300 has a crop factor of 1.53× relative to 35 mm full frame (diagonal 28.2 mm vs 43.3 mm).

What size is the Sony α6300 sensor?

23.5 × 15.6 mm (APS-C), an area of 367 mm² — 42% of full frame.

Is the Sony α6300 full frame?

No — its sensor is APS-C, which is 2.4× smaller in area than full frame.

How many megapixels does the Sony α6300 have?

24.3 megapixels (6,000 × 4,000 pixels), enough for a 20 × 13 inch print at 300 DPI.

What lens mount does the Sony α6300 use?

The Sony α6300 uses the Sony E-mount (flange distance 18.00 mm).

How long can I expose the night sky with the Sony α6300?

With a 13 mm lens (20 mm equivalent) the 500 rule gives 25 s and the stricter NPF rule at f/2.8 gives 17 s.
