Specifications#
- Brand
- Panasonic
- Model
- Lumix DMC-FZ28
- Also known as
- DMC-FZ28, Panasonic DMC FZ28
- Camera type
- Bridge camera
- Sensor size
- 6.1 × 4.8 mm (1/2.3" sensor)
- Crop factor
- 5.60×
- Resolution
- 10.1 MP (3,648 × 2,736 px)
- ISO range
- 100 – 1,600
- Continuous shooting
- 2.5 fps
- Weight
- 417 g (14.7 oz)
- Sensor
- 1/2.33" CCD
- Storage
- SD, SDHC, internal
- Viewfinder
- EVF and 2.7 inch colour LCD (230,000 pixels)
- Exposure modes
- Manual, Program, Automatic, Shutter Priority, Aperture Priority, plus various custom and defined modes
- Flash
- Built-in pop up; Range max 8.5 meters
- Battery
- Battery id CGA-S006 Li-Ion 7.2 V, 710 mAh
- Lens
- 27-486 mm (18x optical zoom) F2.8 - F4.4
- Drive
- 2.5 frame/s, 5 shots
Specifications merged from Wikipedia, Wikidata, Lensfun and openMVG. Spot an error? Tell us.
Sensor size compared#
Focal length equivalents & field of view#
Multiply any focal length by 5.60 to get the full-frame field of view. For fixed-lens cameras use the real focal length printed on the lens (e.g. “6.1–18.3 mm”), not the 35 mm equivalent.
| Lens on this camera | Full-frame equivalent | Horizontal | Vertical | Diagonal |
|---|---|---|---|---|
| 4 mm | 22 mm | 74.5° | 61.6° | 88.0° |
| 4.5 mm | 25 mm | 68.1° | 55.8° | 81.3° |
| 5 mm | 28 mm | 62.6° | 51.0° | 75.4° |
| 6 mm | 34 mm | 53.7° | 43.4° | 65.6° |
| 8 mm | 45 mm | 41.6° | 33.2° | 51.6° |
| 10 mm | 56 mm | 33.8° | 26.8° | 42.3° |
| 12 mm | 67 mm | 28.4° | 22.5° | 35.7° |
| 15 mm | 84 mm | 22.9° | 18.1° | 28.9° |
| 20 mm | 112 mm | 17.3° | 13.6° | 21.9° |
| 25 mm | 140 mm | 13.9° | 10.9° | 17.6° |
| 30 mm | 168 mm | 11.6° | 9.1° | 14.7° |
| 40 mm | 224 mm | 8.7° | 6.8° | 11.0° |
| 50 mm | 280 mm | 7.0° | 5.5° | 8.8° |
| 70 mm | 392 mm | 5.0° | 3.9° | 6.3° |
| 100 mm | 560 mm | 3.5° | 2.7° | 4.4° |
| 150 mm | 840 mm | 2.3° | 1.8° | 3.0° |
Depth of field table#
Total depth of field at each subject distance, using a circle of confusion of 5.4 µm (the 0.030 mm full-frame standard scaled by the crop factor).
| Focal | Aperture | 50.0 cm | 1.00 m | 2.00 m | 3.00 m | 5.00 m | 10.0 m | Hyperfocal |
|---|---|---|---|---|---|---|---|---|
| 4 mm | f/2 | 37.3 cm | 2.40 m | ∞ | ∞ | ∞ | ∞ | 1.50 m |
| 4 mm | f/2.8 | 59.3 cm | 14.6 m | ∞ | ∞ | ∞ | ∞ | 1.07 m |
| 4 mm | f/4 | 1.19 m | ∞ | ∞ | ∞ | ∞ | ∞ | 75.1 cm |
| 4 mm | f/8 | ∞ | ∞ | ∞ | ∞ | ∞ | ∞ | 37.7 cm |
| 8 mm | f/2 | 8.3 cm | 34.2 cm | 1.50 m | 4.01 m | 27.7 m | ∞ | 5.98 m |
| 8 mm | f/2.8 | 11.7 cm | 49.2 cm | 2.39 m | 8.28 m | ∞ | ∞ | 4.27 m |
| 8 mm | f/4 | 16.9 cm | 74.7 cm | 4.81 m | ∞ | ∞ | ∞ | 2.99 m |
| 8 mm | f/8 | 37.0 cm | 2.38 m | ∞ | ∞ | ∞ | ∞ | 1.50 m |
| 14 mm | f/2 | 2.7 cm | 10.8 cm | 44.0 cm | 1.01 m | 2.95 m | 15.6 m | 18.3 m |
| 14 mm | f/2.8 | 3.7 cm | 15.2 cm | 62.2 cm | 1.45 m | 4.47 m | 36.8 m | 13.1 m |
| 14 mm | f/4 | 5.3 cm | 21.8 cm | 91.2 cm | 2.19 m | 7.76 m | ∞ | 9.16 m |
| 14 mm | f/8 | 10.8 cm | 45.2 cm | 2.14 m | 6.83 m | ∞ | ∞ | 4.59 m |
| 22 mm | f/2 | 1.1 cm | 4.3 cm | 17.6 cm | 39.7 cm | 1.12 m | 4.65 m | 45.2 m |
| 22 mm | f/2.8 | 1.5 cm | 6.1 cm | 24.6 cm | 55.9 cm | 1.58 m | 6.84 m | 32.3 m |
| 22 mm | f/4 | 2.1 cm | 8.7 cm | 35.3 cm | 80.5 cm | 2.32 m | 11.0 m | 22.6 m |
| 22 mm | f/8 | 4.2 cm | 17.5 cm | 72.3 cm | 1.70 m | 5.47 m | 80.7 m | 11.3 m |
Equivalent aperture#
Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.
Diffraction & pixel pitch#
With 1.67 µm pixels, diffraction starts to soften pixel-level detail around f/2.5. For maximum sharpness keep landscapes between f/2.8 and f/2; stopping down further trades detail for depth of field.
| Aperture | Airy disk diameter | Spread over | At 100% view |
|---|---|---|---|
| f/2.8 | 3.8 µm | 2.3 px | slight softening |
| f/4 | 5.4 µm | 3.2 px | visibly soft |
| f/5.6 | 7.5 µm | 4.5 px | visibly soft |
| f/8 | 10.7 µm | 6.4 px | visibly soft |
| f/11 | 14.8 µm | 8.9 px | visibly soft |
| f/16 | 21.5 µm | 12.9 px | visibly soft |
| f/22 | 29.5 µm | 17.7 px | visibly soft |
Maximum print sizes#
At 10.1 MP the Panasonic Lumix DMC-FZ28 produces 3,648 × 2,736 pixel images. See the 10 megapixel guide or the print size calculator.
| Resolution | Typical use | Inches | Centimetres |
|---|---|---|---|
| 300 DPI | Photo-lab quality | 12.2 × 9.1 in | 31 × 23 cm |
| 240 DPI | Fine-art inkjet | 15.2 × 11.4 in | 39 × 29 cm |
| 200 DPI | Wall print | 18.2 × 13.7 in | 46 × 35 cm |
| 150 DPI | Poster, viewed from 1 m+ | 24.3 × 18.2 in | 62 × 46 cm |
Night-sky exposure limits#
Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors.
| Focal length | 500 rule | NPF f/1.8 | NPF f/2.8 | NPF f/4 |
|---|---|---|---|---|
| 4 mm (22 mm eq.) | 22.3 s | 28.2 s | 37.0 s | 47.5 s |
| 5 mm (28 mm eq.) | 17.9 s | 22.6 s | 29.6 s | 38.0 s |
| 6 mm (34 mm eq.) | 14.9 s | 18.8 s | 24.7 s | 31.7 s |
| 7 mm (39 mm eq.) | 12.8 s | 16.1 s | 21.1 s | 27.1 s |
| 9 mm (50 mm eq.) | 9.9 s | 12.6 s | 16.4 s | 21.1 s |
Handheld shutter speed guide#
The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.
| Focal length | No stabilisation (1/equiv. focal) | With 3-stop IS | With 5-stop IBIS |
|---|---|---|---|
| 4 mm | 1/25 s | 0.3 s | 1.3 s |
| 9 mm | 1/50 s | 1/6 s | 0.6 s |
| 18 mm | 1/100 s | 1/13 s | 0.3 s |
| 36 mm | 1/200 s | 1/25 s | 1/6 s |
Lens#
The Panasonic Lumix DMC-FZ28 has a built-in, non-interchangeable lens. Use the real focal length of that lens with the tables above; its full-frame equivalent is that number × 5.60.
Similar cameras#
Other 1/2.3" cameras from around the same time.
Frequently asked questions#
What is the crop factor of the Panasonic Lumix DMC-FZ28?
The Panasonic Lumix DMC-FZ28 has a crop factor of 5.60× relative to 35 mm full frame (diagonal 7.7 mm vs 43.3 mm).
What size is the Panasonic Lumix DMC-FZ28 sensor?
6.1 × 4.8 mm (1/2.3"), an area of 29 mm² — 3% of full frame.
Is the Panasonic Lumix DMC-FZ28 full frame?
No — its sensor is 1/2.3", which is 29.8× smaller in area than full frame.
How many megapixels does the Panasonic Lumix DMC-FZ28 have?
10.1 megapixels (3,648 × 2,736 pixels), enough for a 12 × 9 inch print at 300 DPI.
How long can I expose the night sky with the Panasonic Lumix DMC-FZ28?
With a 5 mm lens (28 mm equivalent) the 500 rule gives 18 s and the stricter NPF rule at f/2.8 gives 30 s.
