Specifications#
- Brand
- Lomography
- Model
- Diana
- Also known as
- Diana camera
- Camera type
- Film camera
- Released
- 1960-01-01
- Film format
- Instax Square
- Image area
- 42.0 × 42.0 mm (Medium format 44 × 33 mm)
- Crop factor
- 0.73×
- Sensor type
- Film
Specifications merged from Wikipedia and Wikidata. Spot an error? Tell us.
Sensor size compared#
Focal length equivalents & field of view#
Multiply any focal length by 0.73 to get the full-frame field of view. For fixed-lens cameras use the real focal length printed on the lens (e.g. “6.1–18.3 mm”), not the 35 mm equivalent.
| Lens on this camera | Full-frame equivalent | Horizontal | Vertical | Diagonal |
|---|---|---|---|---|
| 21 mm | 15 mm | 90.0° | 90.0° | 109.5° |
| 23 mm | 17 mm | 84.8° | 84.8° | 104.5° |
| 28 mm | 20 mm | 73.7° | 73.7° | 93.4° |
| 32 mm | 23 mm | 66.5° | 66.5° | 85.7° |
| 35 mm | 25 mm | 61.9° | 61.9° | 80.6° |
| 45 mm | 33 mm | 50.0° | 50.0° | 66.8° |
| 55 mm | 40 mm | 41.8° | 41.8° | 56.7° |
| 63 mm | 46 mm | 36.9° | 36.9° | 50.5° |
| 80 mm | 58 mm | 29.4° | 29.4° | 40.7° |
| 90 mm | 66 mm | 26.3° | 26.3° | 36.5° |
| 110 mm | 80 mm | 21.6° | 21.6° | 30.2° |
| 120 mm | 87 mm | 19.9° | 19.9° | 27.8° |
| 150 mm | 109 mm | 15.9° | 15.9° | 22.4° |
| 180 mm | 131 mm | 13.3° | 13.3° | 18.7° |
| 250 mm | 182 mm | 9.6° | 9.6° | 13.5° |
| 350 mm | 255 mm | 6.9° | 6.9° | 9.7° |
Depth of field table#
Total depth of field at each subject distance, using a circle of confusion of 41.2 µm (the 0.030 mm full-frame standard scaled by the crop factor).
| Focal | Aperture | 50.0 cm | 1.00 m | 2.00 m | 3.00 m | 5.00 m | 10.0 m | Hyperfocal |
|---|---|---|---|---|---|---|---|---|
| 30 mm | f/1.8 | 3.9 cm | 16.1 cm | 66.7 cm | 1.56 m | 4.92 m | 50.4 m | 12.2 m |
| 30 mm | f/2.8 | 6.0 cm | 25.2 cm | 1.08 m | 2.67 m | 10.7 m | ∞ | 7.83 m |
| 30 mm | f/4 | 8.7 cm | 36.7 cm | 1.66 m | 4.63 m | 52.8 m | ∞ | 5.49 m |
| 30 mm | f/8 | 17.7 cm | 81.3 cm | 6.01 m | ∞ | ∞ | ∞ | 2.76 m |
| 59 mm | f/1.8 | 0.9 cm | 4.0 cm | 16.6 cm | 37.7 cm | 1.06 m | 4.43 m | 47.0 m |
| 59 mm | f/2.8 | 1.5 cm | 6.2 cm | 25.8 cm | 59.0 cm | 1.68 m | 7.39 m | 30.2 m |
| 59 mm | f/4 | 2.1 cm | 8.9 cm | 37.1 cm | 85.2 cm | 2.47 m | 12.1 m | 21.2 m |
| 59 mm | f/8 | 4.2 cm | 18.0 cm | 76.1 cm | 1.81 m | 5.99 m | 164 m | 10.6 m |
| 100 mm | f/1.8 | 0.3 cm | 1.3 cm | 5.6 cm | 12.9 cm | 36.4 cm | 1.48 m | 135 m |
| 100 mm | f/2.8 | 0.5 cm | 2.1 cm | 8.8 cm | 20.1 cm | 56.7 cm | 2.31 m | 86.8 m |
| 100 mm | f/4 | 0.7 cm | 3.0 cm | 12.5 cm | 28.7 cm | 81.3 cm | 3.35 m | 60.8 m |
| 100 mm | f/8 | 1.3 cm | 5.9 cm | 25.1 cm | 57.9 cm | 1.66 m | 7.30 m | 30.5 m |
| 165 mm | f/1.8 | 0.1 cm | 0.5 cm | 2.0 cm | 4.6 cm | 13.2 cm | 53.6 cm | 367 m |
| 165 mm | f/2.8 | 0.1 cm | 0.7 cm | 3.1 cm | 7.2 cm | 20.5 cm | 83.5 cm | 236 m |
| 165 mm | f/4 | 0.2 cm | 1.0 cm | 4.4 cm | 10.3 cm | 29.3 cm | 1.19 m | 165 m |
| 165 mm | f/8 | 0.4 cm | 2.0 cm | 8.9 cm | 20.6 cm | 58.7 cm | 2.41 m | 82.8 m |
Equivalent aperture#
Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.
Night-sky exposure limits#
Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors. (NPF needs a known resolution and is omitted here.)
| Focal length | 500 rule |
|---|---|
| 19 mm (14 mm eq.) | 36.1 s |
| 27 mm (20 mm eq.) | 25.4 s |
| 33 mm (24 mm eq.) | 20.8 s |
| 48 mm (35 mm eq.) | 14.3 s |
| 69 mm (50 mm eq.) | 9.9 s |
Handheld shutter speed guide#
The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.
| Focal length | No stabilisation (1/equiv. focal) | With 3-stop IS | With 5-stop IBIS |
|---|---|---|---|
| 33 mm | 1/25 s | 0.3 s | 1.3 s |
| 69 mm | 1/50 s | 1/6 s | 0.6 s |
| 137 mm | 1/100 s | 1/13 s | 0.3 s |
| 275 mm | 1/200 s | 1/25 s | 1/6 s |
Film stocks for the Lomography Diana#
Films currently made in 135 format.
- ADOX CHS 100 II ISO 100
- ADOX CMS 20 II PRO ISO 20
- ADOX Color Mission 200 ISO 200
- ADOX Color Mission Helios ISO 3
- ADOX HR-50 ISO 50
- ADOX Scala 50 ISO 50
- Agfa Copex Rapid ISO 50
- AgfaPhoto APX 100 ISO 100
- AgfaPhoto APX 200 ISO 200
- AgfaPhoto APX 400 ISO 400
- AgfaPhoto Color 400 ISO 400
- Argenti ARF+ Reporter Film Plus ISO 400
- Argenti Nanotomic X ISO 32
- Argenti Pan-X ISO 100
- Argenti Scale-X ISO 100
- Bergger Pancro 400 ISO 400
- CatLABS X FILM 320 ISO 320
- CatLABS X FILM 320 Pro ISO 320
Similar cameras#
Other Medium format 44 × 33 mm film cameras from around the same time.
Frequently asked questions#
What is the crop factor of the Lomography Diana?
The Lomography Diana has a crop factor of 0.73× relative to 35 mm full frame (diagonal 59.4 mm vs 43.3 mm).
What size is the Lomography Diana frame?
42.0 × 42.0 mm (Medium format 44 × 33 mm), an area of 1764 mm² — 204% of full frame.
How long can I expose the night sky with the Lomography Diana?
With a 27 mm lens (20 mm equivalent) the 500 rule gives 25 s.
