Specifications#
- Brand
- Kodak
- Model
- DC3200
- Also known as
- KODAK DC3200 DIGITAL CAMERA
- Camera type
- Large-sensor compact
- Sensor size
- 27.6 × 18.4 mm (APS-H)
- Crop factor
- 1.30×
- Resolution
- 1 MP (1,152 × 864 px)
- Fastest shutter
- 1/500 s
- Weight
- 215 g (7.6 oz)
- Sensor
- CCD
- Storage
- CompactFlash I / 2 MB internal
- Viewfinder
- Optical
- Shutter
- 1/4 s - 1/500 s
- Flash
- Internal, 1.4m - 2.4m range; Auto, Fill-In, Off
- Battery
- Four AA battery
- Dimensions
- 113 x 81 x 53 mm, 4.45 x 3.1 x 2.1 inch
- Lens
- Fixed 39 mm (35 mm equiv.) F3.6
Specifications merged from Wikipedia, Wikidata and openMVG. Spot an error? Tell us.
Sensor size compared#
Focal length equivalents & field of view#
Multiply any focal length by 1.30 to get the full-frame field of view. For fixed-lens cameras use the real focal length printed on the lens (e.g. “6.1–18.3 mm”), not the 35 mm equivalent.
| Lens on this camera | Full-frame equivalent | Horizontal | Vertical | Diagonal |
|---|---|---|---|---|
| 8 mm | 10 mm | 119.9° | 98.1° | 128.6° |
| 10 mm | 13 mm | 108.2° | 85.3° | 117.9° |
| 12 mm | 16 mm | 98.1° | 75.0° | 108.3° |
| 14 mm | 18 mm | 89.3° | 66.7° | 99.8° |
| 16 mm | 21 mm | 81.7° | 59.9° | 92.2° |
| 18 mm | 23 mm | 75.1° | 54.2° | 85.4° |
| 20 mm | 26 mm | 69.3° | 49.5° | 79.4° |
| 24 mm | 31 mm | 59.9° | 42.0° | 69.4° |
| 28 mm | 36 mm | 52.6° | 36.4° | 61.4° |
| 35 mm | 46 mm | 43.1° | 29.5° | 50.8° |
| 40 mm | 52 mm | 38.1° | 25.9° | 45.1° |
| 50 mm | 65 mm | 30.9° | 20.9° | 36.8° |
| 56 mm | 73 mm | 27.7° | 18.7° | 33.1° |
| 70 mm | 91 mm | 22.3° | 15.0° | 26.7° |
| 85 mm | 111 mm | 18.5° | 12.4° | 22.1° |
| 100 mm | 130 mm | 15.7° | 10.5° | 18.9° |
| 135 mm | 176 mm | 11.7° | 7.8° | 14.0° |
| 200 mm | 260 mm | 7.9° | 5.3° | 9.5° |
| 300 mm | 391 mm | 5.3° | 3.5° | 6.3° |
| 400 mm | 521 mm | 4.0° | 2.6° | 4.8° |
| 600 mm | 781 mm | 2.6° | 1.8° | 3.2° |
| 800 mm | 1042 mm | 2.0° | 1.3° | 2.4° |
Depth of field table#
Total depth of field at each subject distance, using a circle of confusion of 23.0 µm (the 0.030 mm full-frame standard scaled by the crop factor).
| Focal | Aperture | 50.0 cm | 1.00 m | 2.00 m | 3.00 m | 5.00 m | 10.0 m | Hyperfocal |
|---|---|---|---|---|---|---|---|---|
| 16 mm | f/1.8 | 7.9 cm | 32.7 cm | 1.43 m | 3.79 m | 23.2 m | ∞ | 6.19 m |
| 16 mm | f/2.8 | 12.4 cm | 52.8 cm | 2.67 m | 10.4 m | ∞ | ∞ | 3.98 m |
| 16 mm | f/4 | 18.0 cm | 81.0 cm | 5.83 m | ∞ | ∞ | ∞ | 2.79 m |
| 16 mm | f/8 | 39.7 cm | 2.85 m | ∞ | ∞ | ∞ | ∞ | 1.40 m |
| 33 mm | f/1.8 | 1.8 cm | 7.4 cm | 30.1 cm | 68.7 cm | 1.96 m | 8.87 m | 26.3 m |
| 33 mm | f/2.8 | 2.8 cm | 11.5 cm | 47.3 cm | 1.09 m | 3.22 m | 18.1 m | 16.9 m |
| 33 mm | f/4 | 4.0 cm | 16.5 cm | 68.5 cm | 1.61 m | 5.11 m | 58.5 m | 11.8 m |
| 33 mm | f/8 | 8.0 cm | 33.6 cm | 1.50 m | 4.03 m | 28.7 m | ∞ | 5.94 m |
| 56 mm | f/1.8 | 0.6 cm | 2.5 cm | 10.3 cm | 23.4 cm | 65.7 cm | 2.68 m | 75.7 m |
| 56 mm | f/2.8 | 0.9 cm | 3.9 cm | 16.0 cm | 36.5 cm | 1.03 m | 4.27 m | 48.7 m |
| 56 mm | f/4 | 1.3 cm | 5.6 cm | 22.9 cm | 52.3 cm | 1.48 m | 6.39 m | 34.1 m |
| 56 mm | f/8 | 2.6 cm | 11.1 cm | 46.3 cm | 1.07 m | 3.17 m | 17.8 m | 17.1 m |
| 92 mm | f/1.8 | 0.2 cm | 0.9 cm | 3.7 cm | 8.6 cm | 24.1 cm | 97.3 cm | 204 m |
| 92 mm | f/2.8 | 0.3 cm | 1.4 cm | 5.8 cm | 13.3 cm | 37.5 cm | 1.52 m | 131 m |
| 92 mm | f/4 | 0.4 cm | 2.0 cm | 8.3 cm | 19.0 cm | 53.6 cm | 2.18 m | 91.9 m |
| 92 mm | f/8 | 0.9 cm | 4.0 cm | 16.6 cm | 38.2 cm | 1.08 m | 4.53 m | 46.0 m |
Equivalent aperture#
Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.
Diffraction & pixel pitch#
With 24.00 µm pixels, diffraction starts to soften pixel-level detail around f/35.8. For maximum sharpness keep landscapes between f/19.7 and f/36; stopping down further trades detail for depth of field.
| Aperture | Airy disk diameter | Spread over | At 100% view |
|---|---|---|---|
| f/2.8 | 3.8 µm | 0.2 px | sharp |
| f/4 | 5.4 µm | 0.2 px | sharp |
| f/5.6 | 7.5 µm | 0.3 px | sharp |
| f/8 | 10.7 µm | 0.4 px | sharp |
| f/11 | 14.8 µm | 0.6 px | sharp |
| f/16 | 21.5 µm | 0.9 px | sharp |
| f/22 | 29.5 µm | 1.2 px | sharp |
Maximum print sizes#
At 1 MP the Kodak DC3200 produces 1,152 × 864 pixel images. See the 2 megapixel guide or the print size calculator.
| Resolution | Typical use | Inches | Centimetres |
|---|---|---|---|
| 300 DPI | Photo-lab quality | 3.8 × 2.9 in | 10 × 7 cm |
| 240 DPI | Fine-art inkjet | 4.8 × 3.6 in | 12 × 9 cm |
| 200 DPI | Wall print | 5.8 × 4.3 in | 15 × 11 cm |
| 150 DPI | Poster, viewed from 1 m+ | 7.7 × 5.8 in | 20 × 15 cm |
Night-sky exposure limits#
Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors.
| Focal length | 500 rule | NPF f/1.8 | NPF f/2.8 | NPF f/4 |
|---|---|---|---|---|
| 11 mm (14 mm eq.) | 34.9 s | 71.2 s | 74.4 s | 78.2 s |
| 15 mm (20 mm eq.) | 25.6 s | 52.2 s | 54.5 s | 57.3 s |
| 18 mm (23 mm eq.) | 21.3 s | 43.5 s | 45.4 s | 47.8 s |
| 27 mm (35 mm eq.) | 14.2 s | 29.0 s | 30.3 s | 31.9 s |
| 38 mm (49 mm eq.) | 10.1 s | 20.6 s | 21.5 s | 22.6 s |
Handheld shutter speed guide#
The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.
| Focal length | No stabilisation (1/equiv. focal) | With 3-stop IS | With 5-stop IBIS |
|---|---|---|---|
| 18 mm | 1/25 s | 0.3 s | 1.3 s |
| 38 mm | 1/50 s | 1/6 s | 0.6 s |
| 77 mm | 1/100 s | 1/13 s | 0.3 s |
| 154 mm | 1/200 s | 1/25 s | 1/6 s |
Lens#
The Kodak DC3200 has a built-in, non-interchangeable lens. Use the real focal length of that lens with the tables above; its full-frame equivalent is that number × 1.30.
Similar cameras#
Other APS-H cameras from around the same time.
Frequently asked questions#
What is the crop factor of the Kodak DC3200?
The Kodak DC3200 has a crop factor of 1.30× relative to 35 mm full frame (diagonal 33.2 mm vs 43.3 mm).
What size is the Kodak DC3200 sensor?
27.6 × 18.4 mm (APS-H), an area of 510 mm² — 59% of full frame.
Is the Kodak DC3200 full frame?
No — its sensor is APS-H, which is 1.7× smaller in area than full frame.
How many megapixels does the Kodak DC3200 have?
1 megapixels (1,152 × 864 pixels), enough for a 4 × 3 inch print at 300 DPI.
How long can I expose the night sky with the Kodak DC3200?
With a 15 mm lens (20 mm equivalent) the 500 rule gives 26 s and the stricter NPF rule at f/2.8 gives 55 s.
