Specifications#
- Brand
- Fujifilm
- Model
- FinePix S9500
- Camera type
- Bridge camera
- Sensor size
- 8.0 × 5.4 mm (1/1.7" sensor)
- Crop factor
- 4.48×
- Resolution
- 9 MP (3,648 × 2,467 px)
- Sensor
- 1/1.6" CCD
- Storage
- xD Picture Card Compact Flash
- Viewfinder
- Electronic viewfinder
- Exposure modes
- Program AE, Aperture Priority AE, Shutter Priority AE, Manual, Program Shift (P mode)
- Lens
- Fixed 28 mm - 300 mm equiv. (10.7x zoom ratio)
Specifications merged from Wikipedia, Wikidata, Lensfun and openMVG. Spot an error? Tell us.
Sensor size compared#
Focal length equivalents & field of view#
Multiply any focal length by 4.48 to get the full-frame field of view. For fixed-lens cameras use the real focal length printed on the lens (e.g. “6.1–18.3 mm”), not the 35 mm equivalent.
| Lens on this camera | Full-frame equivalent | Horizontal | Vertical | Diagonal |
|---|---|---|---|---|
| 4 mm | 18 mm | 90.0° | 68.1° | 100.7° |
| 4.5 mm | 20 mm | 83.3° | 62.0° | 94.0° |
| 5 mm | 22 mm | 77.3° | 56.8° | 88.0° |
| 6 mm | 27 mm | 67.4° | 48.5° | 77.7° |
| 8 mm | 36 mm | 53.1° | 37.4° | 62.2° |
| 10 mm | 45 mm | 43.6° | 30.3° | 51.5° |
| 12 mm | 54 mm | 36.9° | 25.4° | 43.8° |
| 15 mm | 67 mm | 29.9° | 20.4° | 35.7° |
| 20 mm | 90 mm | 22.6° | 15.4° | 27.1° |
| 25 mm | 112 mm | 18.2° | 12.4° | 21.9° |
| 30 mm | 134 mm | 15.2° | 10.3° | 18.3° |
| 40 mm | 179 mm | 11.4° | 7.7° | 13.8° |
| 50 mm | 224 mm | 9.1° | 6.2° | 11.0° |
| 70 mm | 314 mm | 6.5° | 4.4° | 7.9° |
| 100 mm | 448 mm | 4.6° | 3.1° | 5.5° |
| 150 mm | 672 mm | 3.1° | 2.1° | 3.7° |
Depth of field table#
Total depth of field at each subject distance, using a circle of confusion of 6.7 µm (the 0.030 mm full-frame standard scaled by the crop factor).
| Focal | Aperture | 50.0 cm | 1.00 m | 2.00 m | 3.00 m | 5.00 m | 10.0 m | Hyperfocal |
|---|---|---|---|---|---|---|---|---|
| 5 mm | f/2 | 28.5 cm | 1.49 m | ∞ | ∞ | ∞ | ∞ | 1.87 m |
| 5 mm | f/2.8 | 43.1 cm | 3.37 m | ∞ | ∞ | ∞ | ∞ | 1.34 m |
| 5 mm | f/4 | 73.8 cm | ∞ | ∞ | ∞ | ∞ | ∞ | 93.8 cm |
| 5 mm | f/8 | ∞ | ∞ | ∞ | ∞ | ∞ | ∞ | 47.2 cm |
| 10 mm | f/2 | 6.6 cm | 27.0 cm | 1.15 m | 2.86 m | 12.1 m | ∞ | 7.48 m |
| 10 mm | f/2.8 | 9.3 cm | 38.4 cm | 1.73 m | 4.91 m | 75.1 m | ∞ | 5.34 m |
| 10 mm | f/4 | 13.4 cm | 57.0 cm | 2.98 m | 13.4 m | ∞ | ∞ | 3.74 m |
| 10 mm | f/8 | 28.2 cm | 1.48 m | ∞ | ∞ | ∞ | ∞ | 1.88 m |
| 17 mm | f/2 | 2.2 cm | 9.1 cm | 37.1 cm | 84.6 cm | 2.44 m | 11.8 m | 21.6 m |
| 17 mm | f/2.8 | 3.1 cm | 12.8 cm | 52.3 cm | 1.21 m | 3.61 m | 22.3 m | 15.4 m |
| 17 mm | f/4 | 4.5 cm | 18.4 cm | 76.1 cm | 1.80 m | 5.87 m | 129 m | 10.8 m |
| 17 mm | f/8 | 9.0 cm | 37.7 cm | 1.70 m | 4.78 m | 62.9 m | ∞ | 5.41 m |
| 28 mm | f/2 | 0.8 cm | 3.3 cm | 13.5 cm | 30.5 cm | 85.6 cm | 3.51 m | 58.6 m |
| 28 mm | f/2.8 | 1.1 cm | 4.7 cm | 18.9 cm | 42.9 cm | 1.21 m | 5.06 m | 41.8 m |
| 28 mm | f/4 | 1.6 cm | 6.6 cm | 27.1 cm | 61.6 cm | 1.75 m | 7.71 m | 29.3 m |
| 28 mm | f/8 | 3.2 cm | 13.3 cm | 54.9 cm | 1.27 m | 3.84 m | 25.4 m | 14.7 m |
Equivalent aperture#
Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.
Diffraction & pixel pitch#
With 2.19 µm pixels, diffraction starts to soften pixel-level detail around f/3.3. For maximum sharpness keep landscapes between f/2.8 and f/3; stopping down further trades detail for depth of field.
| Aperture | Airy disk diameter | Spread over | At 100% view |
|---|---|---|---|
| f/2.8 | 3.8 µm | 1.7 px | sharp |
| f/4 | 5.4 µm | 2.4 px | slight softening |
| f/5.6 | 7.5 µm | 3.4 px | visibly soft |
| f/8 | 10.7 µm | 4.9 px | visibly soft |
| f/11 | 14.8 µm | 6.7 px | visibly soft |
| f/16 | 21.5 µm | 9.8 px | visibly soft |
| f/22 | 29.5 µm | 13.5 px | visibly soft |
Maximum print sizes#
At 9 MP the Fujifilm FinePix S9500 produces 3,648 × 2,467 pixel images. See the 8 megapixel guide or the print size calculator.
| Resolution | Typical use | Inches | Centimetres |
|---|---|---|---|
| 300 DPI | Photo-lab quality | 12.2 × 8.2 in | 31 × 21 cm |
| 240 DPI | Fine-art inkjet | 15.2 × 10.3 in | 39 × 26 cm |
| 200 DPI | Wall print | 18.2 × 12.3 in | 46 × 31 cm |
| 150 DPI | Poster, viewed from 1 m+ | 24.3 × 16.4 in | 62 × 42 cm |
Night-sky exposure limits#
Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors.
| Focal length | 500 rule | NPF f/1.8 | NPF f/2.8 | NPF f/4 |
|---|---|---|---|---|
| 4 mm (18 mm eq.) | 27.9 s | 32.2 s | 40.9 s | 51.4 s |
| 5 mm (22 mm eq.) | 22.3 s | 25.8 s | 32.8 s | 41.2 s |
| 6 mm (27 mm eq.) | 18.6 s | 21.5 s | 27.3 s | 34.3 s |
| 8 mm (36 mm eq.) | 14.0 s | 16.1 s | 20.5 s | 25.7 s |
| 11 mm (49 mm eq.) | 10.1 s | 11.7 s | 14.9 s | 18.7 s |
Handheld shutter speed guide#
The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.
| Focal length | No stabilisation (1/equiv. focal) | With 3-stop IS | With 5-stop IBIS |
|---|---|---|---|
| 5 mm | 1/25 s | 0.3 s | 1.3 s |
| 11 mm | 1/50 s | 1/6 s | 0.6 s |
| 22 mm | 1/100 s | 1/13 s | 0.3 s |
| 45 mm | 1/200 s | 1/25 s | 1/6 s |
Lens#
The Fujifilm FinePix S9500 has a built-in, non-interchangeable lens. Use the real focal length of that lens with the tables above; its full-frame equivalent is that number × 4.48.
Similar cameras#
Other 1/1.7" cameras from around the same time.
Frequently asked questions#
What is the crop factor of the Fujifilm FinePix S9500?
The Fujifilm FinePix S9500 has a crop factor of 4.48× relative to 35 mm full frame (diagonal 9.7 mm vs 43.3 mm).
What size is the Fujifilm FinePix S9500 sensor?
8.0 × 5.4 mm (1/1.7"), an area of 43 mm² — 5% of full frame.
Is the Fujifilm FinePix S9500 full frame?
No — its sensor is 1/1.7", which is 20.0× smaller in area than full frame.
How many megapixels does the Fujifilm FinePix S9500 have?
9 megapixels (3,648 × 2,467 pixels), enough for a 12 × 8 inch print at 300 DPI.
How long can I expose the night sky with the Fujifilm FinePix S9500?
With a 5 mm lens (22 mm equivalent) the 500 rule gives 22 s and the stricter NPF rule at f/2.8 gives 33 s.
