Specifications#
- Brand
- Canon
- Model
- EOS R10
- Camera type
- Mirrorless
- Released
- 2022-07-28
- Lens mount
- Canon RF
- Sensor size
- 22.3 × 14.9 mm (APS-C (Canon))
- Crop factor
- 1.61×
- Resolution
- 24.2 MP (6,000 × 4,000 px)
- ISO range
- 100 – 32,000
- Fastest shutter
- 1/4,000 s
- Continuous shooting
- 15 fps
- Max video resolution
- 4K
- Weight
- 426 g (15.0 oz)
- Sensor type
- CMOS
- AF points / area
- 651 zones / 4503 positions (photo); 527 zones / 3713 positions (video)
- Shutter
- Electronically-controlled focal-plane shutter; Electronic first-curtain; Electronic rolling shutter
- Flash
- Hot shoe, built-in
- Battery
- LP-E17
- Dimensions
- 122.5 *
- Lens
- Interchangeable
- Predecessor
- Canon EOS 90D and 850D (DSLRs); Canon EOS M5 (EF-M mirrorless)
- Made in
- Japan
- Launch price
- USD 979.99 (body only); USD 1099 (with RF-S 18-45mm f/4.5-6.3 IS STM); USD 1379 (with RF-S 18-150mm f/3.5-6.3 IS STM)
- Video
- 4K UHD at up to 29.97 fps (59.94 fps with crop), 1080p at up to 119.88 fps
Specifications merged from Wikipedia, Wikidata and Lensfun. Spot an error? Tell us.
Sensor size compared#
Focal length equivalents & field of view#
Multiply any focal length by 1.61 to get the full-frame field of view. Angles are for a rectilinear lens focused at infinity.
| Lens on this camera | Full-frame equivalent | Horizontal | Vertical | Diagonal |
|---|---|---|---|---|
| 8 mm | 13 mm | 108.7° | 85.9° | 118.4° |
| 10 mm | 16 mm | 96.2° | 73.4° | 106.6° |
| 12 mm | 19 mm | 85.8° | 63.7° | 96.4° |
| 14 mm | 23 mm | 77.1° | 56.0° | 87.5° |
| 16 mm | 26 mm | 69.7° | 49.9° | 79.9° |
| 18 mm | 29 mm | 63.6° | 45.0° | 73.4° |
| 20 mm | 32 mm | 58.3° | 40.9° | 67.7° |
| 24 mm | 39 mm | 49.8° | 34.5° | 58.4° |
| 28 mm | 45 mm | 43.4° | 29.8° | 51.2° |
| 35 mm | 56 mm | 35.3° | 24.0° | 41.9° |
| 40 mm | 65 mm | 31.2° | 21.1° | 37.1° |
| 50 mm | 81 mm | 25.1° | 16.9° | 30.0° |
| 56 mm | 90 mm | 22.5° | 15.2° | 26.9° |
| 70 mm | 113 mm | 18.1° | 12.2° | 21.7° |
| 85 mm | 137 mm | 14.9° | 10.0° | 17.9° |
| 100 mm | 161 mm | 12.7° | 8.5° | 15.3° |
| 135 mm | 218 mm | 9.4° | 6.3° | 11.3° |
| 200 mm | 323 mm | 6.4° | 4.3° | 7.7° |
| 300 mm | 484 mm | 4.3° | 2.8° | 5.1° |
| 400 mm | 645 mm | 3.2° | 2.1° | 3.8° |
| 600 mm | 968 mm | 2.1° | 1.4° | 2.6° |
| 800 mm | 1291 mm | 1.6° | 1.1° | 1.9° |
Depth of field table#
Total depth of field at each subject distance, using a circle of confusion of 18.6 µm (the 0.030 mm full-frame standard scaled by the crop factor). Detailed tables: 24 mm f/1.8, 24 mm f/2.8, 35 mm f/1.8, 35 mm f/2.8, 50 mm f/1.8, 50 mm f/2.8.
| Focal | Aperture | 50.0 cm | 1.00 m | 2.00 m | 3.00 m | 5.00 m | 10.0 m | Hyperfocal |
|---|---|---|---|---|---|---|---|---|
| 14 mm | f/1.8 | 8.4 cm | 34.7 cm | 1.53 m | 4.14 m | 31.0 m | ∞ | 5.87 m |
| 14 mm | f/2.8 | 13.1 cm | 56.2 cm | 2.92 m | 12.8 m | ∞ | ∞ | 3.78 m |
| 14 mm | f/4 | 19.1 cm | 87.0 cm | 6.98 m | ∞ | ∞ | ∞ | 2.65 m |
| 14 mm | f/8 | 42.7 cm | 3.40 m | ∞ | ∞ | ∞ | ∞ | 1.33 m |
| 27 mm | f/1.8 | 2.2 cm | 9.0 cm | 36.5 cm | 83.5 cm | 2.41 m | 11.6 m | 21.8 m |
| 27 mm | f/2.8 | 3.4 cm | 14.0 cm | 57.5 cm | 1.33 m | 4.06 m | 28.9 m | 14.0 m |
| 27 mm | f/4 | 4.8 cm | 20.1 cm | 83.9 cm | 2.00 m | 6.83 m | ∞ | 9.83 m |
| 27 mm | f/8 | 9.7 cm | 41.3 cm | 1.92 m | 5.76 m | ∞ | ∞ | 4.93 m |
| 46 mm | f/1.8 | 0.7 cm | 3.0 cm | 12.4 cm | 28.1 cm | 78.9 cm | 3.23 m | 63.3 m |
| 46 mm | f/2.8 | 1.1 cm | 4.7 cm | 19.3 cm | 43.8 cm | 1.24 m | 5.21 m | 40.7 m |
| 46 mm | f/4 | 1.6 cm | 6.7 cm | 27.6 cm | 63.0 cm | 1.80 m | 7.97 m | 28.5 m |
| 46 mm | f/8 | 3.2 cm | 13.5 cm | 56.0 cm | 1.30 m | 3.96 m | 27.4 m | 14.3 m |
| 76 mm | f/1.8 | 0.2 cm | 1.1 cm | 4.5 cm | 10.2 cm | 28.6 cm | 1.15 m | 173 m |
| 76 mm | f/2.8 | 0.4 cm | 1.7 cm | 6.9 cm | 15.8 cm | 44.5 cm | 1.80 m | 111 m |
| 76 mm | f/4 | 0.5 cm | 2.4 cm | 9.9 cm | 22.6 cm | 63.7 cm | 2.60 m | 77.7 m |
| 76 mm | f/8 | 1.1 cm | 4.8 cm | 19.9 cm | 45.4 cm | 1.29 m | 5.47 m | 38.9 m |
Equivalent aperture#
Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.
Diffraction & pixel pitch#
With 3.72 µm pixels, diffraction starts to soften pixel-level detail around f/5.5. For maximum sharpness keep landscapes between f/3.0 and f/6; stopping down further trades detail for depth of field.
| Aperture | Airy disk diameter | Spread over | At 100% view |
|---|---|---|---|
| f/2.8 | 3.8 µm | 1.0 px | sharp |
| f/4 | 5.4 µm | 1.4 px | sharp |
| f/5.6 | 7.5 µm | 2.0 px | slight softening |
| f/8 | 10.7 µm | 2.9 px | slight softening |
| f/11 | 14.8 µm | 4.0 px | visibly soft |
| f/16 | 21.5 µm | 5.8 px | visibly soft |
| f/22 | 29.5 µm | 7.9 px | visibly soft |
Maximum print sizes#
At 24.2 MP the Canon EOS R10 produces 6,000 × 4,000 pixel images. See the 24 megapixel guide or the print size calculator.
| Resolution | Typical use | Inches | Centimetres |
|---|---|---|---|
| 300 DPI | Photo-lab quality | 20.0 × 13.3 in | 51 × 34 cm |
| 240 DPI | Fine-art inkjet | 25.0 × 16.7 in | 64 × 42 cm |
| 200 DPI | Wall print | 30.0 × 20.0 in | 76 × 51 cm |
| 150 DPI | Poster, viewed from 1 m+ | 40.0 × 26.7 in | 102 × 68 cm |
Night-sky exposure limits#
Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors.
| Focal length | 500 rule | NPF f/1.8 | NPF f/2.8 | NPF f/4 |
|---|---|---|---|---|
| 9 mm (15 mm eq.) | 34.4 s | 19.4 s | 23.3 s | 27.9 s |
| 12 mm (19 mm eq.) | 25.8 s | 14.5 s | 17.5 s | 21.0 s |
| 15 mm (24 mm eq.) | 20.7 s | 11.6 s | 14.0 s | 16.8 s |
| 22 mm (35 mm eq.) | 14.1 s | 7.9 s | 9.5 s | 11.4 s |
| 31 mm (50 mm eq.) | 10.0 s | 5.6 s | 6.8 s | 8.1 s |
Handheld shutter speed guide#
The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.
| Focal length | No stabilisation (1/equiv. focal) | With 3-stop IS | With 5-stop IBIS |
|---|---|---|---|
| 15 mm | 1/25 s | 0.3 s | 1.3 s |
| 31 mm | 1/50 s | 1/6 s | 0.6 s |
| 62 mm | 1/100 s | 1/13 s | 0.3 s |
| 124 mm | 1/200 s | 1/25 s | 1/6 s |
Lenses for the Canon EOS R10#
Native Canon RF lenses in our database (48 total). Also adaptable: T-mount (T2), Canon EF, M42 screw mount, Deckel (DKL), Canon EF-S, M39 / LTM (Leica thread).
- Canon RF-S 18-150mm F3.5-6.3 IS STM 18–150 mm
- Canon RF 24mm F1.4 L VCM 24 mm
- Canon RF 24mm F1.8 MACRO IS STM 24 mm
- Canon RF 28-70mm F2.8 IS STM 28–70 mm
- Canon RF 50mm F1.2 L USM 50 mm
- Canon RF 50mm F1.4 L VCM 50 mm
- Canon RF 135mm F1.8L IS USM 135 mm
- Canon RF 10-20mm f/4L IS STM 10–20 mm
- Canon RF-S 10-18mm F4.5-6.3 IS STM 10–18 mm
- Laowa 10mm f/2.8 Zero-D FF 10 mm
- Sigma 10-18mm F2.8 DC DN | Contemporary 023 10–18 mm
- Tamron 11-20mm f/2.8 Di III-A RXD (B060) 11–20 mm
- Canon RF 14-35mm F4 L IS USM 14–35 mm
- Canon RF 15-30mm F4.5-6.3 IS STM 15–30 mm
- Canon RF 15-35mm F2.8L IS USM 15–35 mm
- Laowa 15mm f/2.0 Zero-D 15 mm
- Canon RF 16mm F2.8 STM 16 mm
- Sigma 16-300mm F3.5-6.7 DC OS | C 16–300 mm
- Sigma 16mm f/1.4 DC DN Contemporary 16 mm
- Sigma 17-40mm F1.8 DC | Art 025 17–40 mm
- Tamron 17-70mm F/2.8 Di III-A VC RXD 17–70 mm
- Canon RF-S 18-45mm F4.5-6.3 IS STM 18–45 mm
- Sigma 18-50mm F2.8 DC DN | Contemporary 021 18–50 mm
- Tamron 18-300mm F3.5-6.3 B061 RF 18–300 mm
- Canon RF 24-105mm F4-7.1 IS STM 24–105 mm
- Canon RF 24-105mm F4L IS USM 24–105 mm
- Canon RF 24-240mm F4-6.3 IS USM 24–240 mm
- Canon RF 24-50mm F4.5-6.3 IS STM 24–50 mm
- Canon RF 24-70mm F2.8L IS USM 24–70 mm
- Canon RF 28-70mm F2 L USM 28–70 mm
- Canon RF 28mm F2.8 STM 28 mm
- Sigma 30mm f/1.4 DC DN 30 mm
- Canon RF 35mm F1.4 L VCM 35 mm
- Canon RF 35mm F1.8 MACRO IS STM 35 mm
- Canon RF 45mm F1.2 STM 45 mm
- Canon RF 50mm F1.8 STM 50 mm
Frequently asked questions#
What is the crop factor of the Canon EOS R10?
The Canon EOS R10 has a crop factor of 1.61× relative to 35 mm full frame (diagonal 26.8 mm vs 43.3 mm).
What size is the Canon EOS R10 sensor?
22.3 × 14.9 mm (APS-C (Canon)), an area of 332 mm² — 38% of full frame.
Is the Canon EOS R10 full frame?
No — its sensor is APS-C (Canon), which is 2.6× smaller in area than full frame.
How many megapixels does the Canon EOS R10 have?
24.2 megapixels (6,000 × 4,000 pixels), enough for a 20 × 13 inch print at 300 DPI.
What lens mount does the Canon EOS R10 use?
The Canon EOS R10 uses the Canon RF (flange distance 20.00 mm).
How long can I expose the night sky with the Canon EOS R10?
With a 12 mm lens (19 mm equivalent) the 500 rule gives 26 s and the stricter NPF rule at f/2.8 gives 17 s.
